47
After the confirmation, the device is bypassed and the message appears that the device is
bypassed.
If the device is already bypassed the user is prompted to un-bypass the circuit.
After the confirmation, the device is un-bypassed and the information message shows that the
device is un-bypassed.
2. Groups
Configured bypass groups can be bypassed using this option. The list of all the configured
bypass groups is displayed and the user can select which group to bypass.
Scroll up/down to select group and press Enter. If the group selected is not bypassed the user
is prompted to bypass the group.
After the confirmation the group is bypassed and the message appears that the group is
bypassed.
If the group is already bypassed, the user is prompted to un-bypass the group.
After the confirmation, the group is un-bypassed and the message is that the group is un-
bypassed.
3. Loop
The whole loop either conventional or addressable can be bypassed using this option. The
user is prompted to enter the loop number to be bypassed.
Device /circuit
Bypassed
Device now bypassed
Unbypass ?Y/N
Device /circuit
Unbypassed
Group
Bypassed
Group
Unbypassed
