5.11.7 Auxiliary Disconnect
The auxiliary disconnect operation is performed by the following the steps below. If the
auxiliary relays are connected the user is prompted to disconnect the relays.
After the confirmation the auxiliary relays are disconnected and the information message is
displayed that the auxiliary relays are disconnected.
If the auxiliary relays are already disconnected the user is prompted to reconnect the relays.
After the confirmation the auxiliary relays are reconnected and the information message is
displayed that the auxiliary relays are reconnected.
5.11.8 Test Dialer
Special function is provided to test the dialer operation. This function can manually test both
the phone line L1 and L2 and also reset the dialer where all the events to be reported in the
queue are cleared and the dialer status is reset.
5.11.9 After Hours
This operation allows to manually set the daytime or the night time mode of operation thus
over-riding the current daytime or nighttime mode. The user is prompted for confirmation as
shown below:
After the confirmation the user is prompted to enter which mode to be set.
After the user selection and information message is displayed that the daytime nighttime mode
is updated.
Aux relays connected
Disconnect ?Y/N
Aux relays
disconnected
Aux rly disconnected
Reconnect ?Y/N
Aux relays
Reconnected
---Dialer test ----
1. L#1 manual test
2. L#2 manual test
3. Reset dialer
Manual night mode
Change ?Y/N
Select mode
1. Daytime
2. Night time
