Paging Operation
46
Paging Operation
This section describes the controls and indicators on the QMP-5100B and QMP-5101B Master Paging and QZP-
5101 Paging Selector Modules.
QMP-5100B
AC ON LED
This green LED illuminates steadily to Indicate that AC power is present.
QMP-5101B Displays
Common Trouble LED
Flashes amber to indicate any QX-5000 trouble.
Mic Trouble LED
Flashes amber to indicate a microphone trouble.
Mic Level LED
Illuminates steady green to indicate the paging audio level.
Amplifier Trouble LED
Indicates any QX-5000 amplifier internal trouble.
Circuit Trouble LED
Indicates any QX-5000 amplifier field wiring trouble.
Remote Failure LED
Indicates an RS-485 communications failure.
Page Inhibit LED
Indicates that Mic or Warden Paging is inhibited.
All-Call
Illuminates steady green to indicate that the All-Call function is active. This LED will not function if the DIP switch
SW1-5 is set to ON.
All-Call Minus
Illuminates steady green to indicate that the All-Call Minus function is active. This LED will not function if the DIP
switch SW1-5 is set to ON.
Warden Page
Illuminates steady green to indicate that the Warden Page function is active.
QMP-5100B/QMP-5101B Controls
Reset Button
Performs a system reset on the QX-5000 (not the fire alarm).
Lamp Test Button
Momentarily activates all LED indicators.
All-Call Button
Selects all zones for voice paging. This button will not function if DIP switch SW1-5 Automatic All-Call is set to ON.
To Next Page
