QX-5000 Series Installation and Operation Manual

Appendix A: Specifications

ULC Specifications

Overall

• Zero to 49 degrees Celsius, 0 to 95% RH (non-condensing) operating range

• Power input: 120 VAC, 60Hz, 12A (primary)

• Power supply ratings: 30A, 40V (secondary)

• ULC requires use of Wuhan Sota Enertech Inc batteries

Model QIF-5000B Interface Module

• Two Class B Indicating circuits, one silenceable, one non-silenceable circuit connect to a fire alarm control

panel

• One trouble contact output to a fire alarm control panel

• One GA contact input from a fire alarm control panel to allow two-stage operation

• One bell cut drive for an external bell cut relay to a fire alarm control panel

• Fully supervised interface to QMP-5100B master paging module

• Microcontroller based with full Watchdog Timer operation

• One minute paging inhibit after the first alarm

• Supervised pre-amplifier & tone generators

•Lamp test

• 18-1/2" high, 5-1/4" deep

• Current consumption: standby: 200mA

alarm: 200mA

Model QPS-5000 & QBC-5000B Power Supply & Charger

• Primary input: 120 VAC, 60Hz, 12Amp

• Charging for up to 65 AH of 24 VDC batteries

• Float type charger

Model QMB-5000B Motherboard and Card Cage

• Accommodates one QIF-5000B, and up to 7 amplifiers (360 Watts MAX speaker load). Connections for QPS-

5000, QBC-5000B, batteries, and expansion connection to another QMB-5000B

Model QAA-5160-70/25 Amplifier with one 70V or 25V, 60 Watt Zone

• 70.7Vrms or 25V constant voltage output

• One fully supervised Class "A" or "B" speaker zone

• 60 watts per zone

• Freq. response +/-3dB from 400 to 4000Hz

• Harmonic distortion less than 2.5% at 1 KHz

• Current consumption: standby: 55mA

alarm: 350mA, plus 65mA/watt speaker power

Note: All circuits are power limited.
