QX-5000 Series Installation and Operation Manual
85
Appendix D: Power Supply & Batteries
Use the form below to determine the required main chassis and secondary power supply (batteries).
Total Current Requirement: ALARM (B)______ Amps.
Battery Capacity Requirement
([STANDBY (A) ______ ] X [(24 or 60 Hours) ___ ]) + ([ALARM (B) ______ ] X [
♣
Alarm in Hr.] _____) = (C) ______AH
Battery Selection: Multiply answer above (C) by 1.20 to derate battery.
Batteries: BA-124 (24AH), BA-140 (40AH), and BA-165(65AH).
Above 40AH, batteries require a separate box (model BC-160).
♣
Use 0.084 for five minutes of alarm or 0.5 for thirty minutes of alarm as a multiplier figure.
IMPORTANT NOTICE
The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power
without provision of any disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current
circuit protection that complies with the local codes. Refer to Appendix A on page 75 for specifications.
Power Requirements (All currents are in amperes)
Model Number Description
Qty
Standby
(Amps)
Total
Standby
(Amps)
Alarm
(Amps)
Total
Alarm
(Amps)
QIF-5000B Interface 1 X 0.200 = 0.200 =0.200
QAA-5160-70/25 1 Zone 60W Amplifier X 0.055 = 0.350 =
QAA-5230-70/25 2 Zone 30W Amplifier X 0.055 = 0.350 =
QAA-5230S-70/25 2 Zone 30W Amplifier (split) X 0.055 = 0.350 =
QAA-5230S-525-
70/25
2 Zone 30W Amplifier (split) X 0.055 = 0.350 =
QAA-5415-70 4 Zone 15W Amplifier, 70V X 0.055 = 0.350 =
QAA-5415-25 4 Zone 15W Amplifier, 25V X 0.055 = 0.350 =
QMP-5100B/QMP-5101B
Master Paging Module X 0.031 = 0.081 =
QMP-5100AX Paging Multiplex Module X 0.031 = 0.081 =
QMP-5100MSB Microphone Splitter Board X 0.130 = 0.275 =
QZP-5101 Paging Zone Module X 0.010 = 0.015 =
QMT-5300A/QMT -5302
Master Telephone Module X 0.040 = 0.040 =
QZT-5302 Telephone Zone Module X 0.026 = 0.026 =
QIF-1000 Interface Module X 0.180 = 0.200 =
QIF-2000 Interface Module X 0.010 = 0.010 =
QDV-1000 Digitized Voice Module X 0.030 = 0.030 =
Total audio power in watts
0.065/watt
=
Total audio power in watts for QAA-5415-70 or -25 0.075/watt
=
Total currents (Add above currents) STANDBY (A)(B)
