QIF-5000B Configuration Download Procedure
62
Configure the QDV-1000 Channel 4 as show in the diagram below. Also note that the ‘Message’ of ‘Part 1' is the
message number of the Pre-announce tone recorded in Alert2 I.C.
Note: The Fire Alarm Output Features of the QX-5000 Audio System are only available on the QX-
5000 that is directly connected to the fire alarm system and these Fire Alarm Output Features are not
transmitted to the other QX-5000 Audio Systems through the QIF-1000.
To Next Page
