Mircom TX3 Series - Figure 22. Add Residents - Second Window

Residents
TX3 Nano Configuration Manual 43
Copyright 2019
4. Click Next.
Figure 22. Add Residents - second window
5. Provide the following information in the right pane:
Location. Enter the resident’s address.
Allow incoming SIP calls. Select Yes to allow this resident to call the
TX3 Nano. The default is No.
Calls to the TX3 Nano must be SIP calls. The TX3 Nano does not accept
video. When a call is made to the TX3 Nano, the TX3 Nano does not ring;
it answers automatically.
Type. Select Phone Number, SIP Username, or NSL.
Phone Number. If you selected Phone Number, enter the PSTN phone
number for the resident. Type a comma (,) for a 1 second pause, and type
a semicolon (;) for a 3 second pause.
Note: Do not include brackets, dashes, or spaces in the phone number.
SIP Username. If you selected SIP Username, enter the SIP username
for the resident.
