5-50 Switches and controls
1 Regeneration controlling DPF system
1.1 Controls and indicators
DPF cleaning switch
Use this switch for parked DPF regeneration to burn
PM in the DPF.
Multi-information display
The multi-information display indicates the amount
of PM in the DPF, a prompt for performing parked
DPF regeneration, the predicted time until comple-
tion of parked DPF regeneration, and warnings.
MODE switch
Use this switch for selecting and setting indications
on the multi-information display.
DPF indicator lamp
This lamp lights or flashes to indicate the state of
the DPF.
Z23271
