6-3
• The water temperature gauge is displayed on
the multi-information display and indicates the
temperature of the engine coolant.
• With the engine running normally, the coolant
temperature indicator will indicate around the
middle point of the scale.
• If the coolant temperature becomes abnormally
high, the multi-information display will show
in amber. The vehicle can still be driven.
• If the coolant temperature becomes even higher,
the indication on the multi-information dis-
play will change from amber to red and the
warning lamp will come on. The engine power
will be reduced, but the vehicle can still be
driven.
• If the engine overheats, the indication (red)
and warning lamp on the multi-information
display will stay illuminated and a buzzer will
sound.
• When the engine has overheated, perform the
checks and corrective steps described on this
reference page: P. 13-8
Water temperature gauge
Z22060
