9-14 Heating and air conditioning

• Blowing air toward your feet

• Blowing air toward your feet and the wind-

shield

• Blowing air toward the windshield

2.6 Stopping all operations

Set the air volume adjustment dial to OFF.

Z21379

Z21380

Z21381

Z21068

FE_FG.book Page 14 Monday, December 19, 2011 4:22 PM
