Mitsubishi Fuso Canter 2013

To Next Page

To Previous Page

2-4 Warning labels

2 On driver’s door and door pillar

Location Category Information Ref. page

CAUTION Handling of PTO <option> 5-45

WARNING Handling of DUONIC

5-20

WARNING 4WD <FG> 8-1

CAUTION Towing precautions 13-32

Standard value Tire pressure 12-67

WARNING 113-liter fuel tank refilling precaution 1-5

WARNING

Precautions for vehicles with limited slip differential

<FE: option; FG: standard>

12-70

Z21446
