2-6 Warning labels

2 On cab outside and engine

Location Category Information Ref. page

WARNING

Handling of cab tilt function (Vehicles other than

Crew-cab models)

12-6

WARNING Handling of pressure cap 12-57

CAUTION Inspection and replacement of engine oil 12-23

CAUTION Oil to use for clutch and transmission 12-28

Z21197
