12-5

2 Power steering fluid and engine coolant

level inspection opening

In front of the rear seat, there is an opening for

inspecting and replenishing the power steering fluid

and engine coolant.

Uncover and cover the opening as follows:

1. Remove the cover .

2. Raise the clamp to unhook it and then swing

down the inspection opening cover .

Perform the above procedure in reverse to

cover the opening.
