12-83
1 Removal and installation of battery
cover
1. Remove the two wing bolts . Pull the cover
toward you to remove it from the stoppers .
2. To fit the cover, follow the removal steps in
reverse. After fitting the cover, make sure it is
securely retained.
Battery – check
Inspection
intervals
At the time of pre-operational
check
WARNING
• The battery generates flammable hydro-
gen gas and should be kept away from
open flame and spark.
• When removing the battery, always dis-
connect the negative (–) terminal first and
reconnect it last. A spark can occur if a
tool touches the positive (+) terminal and
frame with the negative (–) terminal con-
nected.
• When handling the battery, wear safety
goggles to protect your eyes.
• Perform all battery checks with the engine
turned off.
Z23269
