9-2 Heating and air conditioning
1 Adjusting the airflow direction
•
Adjust the up/down direction of airflow from
each outlet as desired by moving up or down the
knob or fin .
• Adjust the left/right direction of airflow from each
outlet as desired by pressing the right or left side
of the outlet.
• Close each outlet by moving the knob or fin fully
downward. The outlet opens if the knob or fin is
moved upward.
NOTE:
Avoid placing anything between the windshield and
instrument panel, as it will block the necessary air-
flow toward the windshield.
Front air outlets
Z21365
Z21366
