6-30 Instruments and warning lamps
NOTE:
Illumination of any warning lamp marked (*) is accompanied by sounding of a buzzer.
DPF indicator lamp
Slow flashing
(0.5-second inter-
val; amber)
DPF contains a
lot of PM
5-50
Fast flashing
(0.25-second
interval; amber)
Illumination
(amber)
Parked DPF
regeneration in
progress
Illumination
(green)
Automatic DPF
regeneration in
progress
DEF warning lamp
• Quantity of DEF in DEF tank has
fallen too low
• Abnormality detected in NOx
sensor
5-58
•
DEF level warning lamp
Quantity of DEF in DEF tank has
fallen too low
5-58
Engine immobilizer warning
lamp
• Disturbed communication with
engine immobilizer starter key
• Fault in engine immobilizer
6-36
Lamp
symbol
Warning/indicator lamp If illuminates or flashes
Ref.
page
