12-49
3. Pull element straight down to remove.
• Installation
1. Insert the air cleaner element into the air cleaner
element case in a straight line.
2. Move the lock lever in the air cleaner element
case to the “LOCK” position.
3. Install the cover on the case by inserting the
projections on the cover into the holes in
the case and then fasten the clamps.
CAUTION
Install the air cleaner element in the case and
close the case completely. A broken packing or
loose fastening of the clamps will cause dust or
other foreign material to be sucked in by the
engine, causing the pistons and cylinder liners
to become worn prematurely.
Z21181
Z21182
Z21183
