13-15

F15 10A Audio system

F16 20A –

F17 20A Fuel heater

F18 10A ABS control unit

F19 15A Engine control unit

F20 10A –

F21 10A –

F22 15A

Meter cluster, air condi-

tioner control, rear air con-

ditioner

F23 10A –

F24 10A DUONIC

control unit

F25 10A

Accessory power supply

(starter switch ACC circuit)

F26 10A

Accessory power supply

(battery circuit)

F27 20A Van body dome lamp

F28 15A Engine control unit

F29 20A SCR system

F30 20A SCR system

F31 20A Engine control unit

F32 10A

Air conditioner compres-

sor clutch

F33 – –

F34 15A Fuel pump

F35 – –

F36 20A DUONIC

control unit

F37 10A Rear Blower fan motor

F38 15A Rear condenser fan motor

F39 – –

F40 20A A/C condenser fan

F41 30A ABS control unit

F42 – –

Fuse

No.

Amperage Protected circuit

FE_FG.book Page 15 Monday, December 19, 2011 4:22 PM
