Mitsubishi FX3U Series Programming Manual

915
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
B Instruction Execution Time
B-4 Applied Instruction Execution Time
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
Character string control
206 MIDR 25 + 0.59n + 0.68m ⎯ 0.455 ⎯
n: Character position
m: Number of characters
207 MIDW 25.8 + 0.3m + 0.44n ⎯ 0.455 ⎯
n: Character position
m: Number of stored
characters
208 INSTR 20.6 + 2.98m ⎯ 0.585 ⎯
m: Number of searched
characters
*1
209 $MOV 16 + 1.52n ⎯ 0.325 ⎯
*1. Number of characters from the head of the searched character string to detected character
Data operation 3
210 FDEL 43 + 0.95m ⎯⎯⎯
m: Number of data shifted
forward
*2
211 FINS 63 + 0.98m ⎯⎯⎯
m: Number of data shifted
backward
*3
212 POP 7.8 ⎯ 0.455 ⎯
213 SFR 9.3 ⎯ 0.325 ⎯
214 SFL 9.3 ⎯ 0.325 ⎯
215 ⎯⎯ ⎯ ⎯ ⎯
216 ⎯⎯ ⎯ ⎯ ⎯
217 ⎯⎯ ⎯ ⎯ ⎯
218 ⎯⎯ ⎯ ⎯ ⎯
219 ⎯⎯ ⎯ ⎯ ⎯
*2. m = (Number of data tables) - (Table position of deleted data)
Number of data tables: Present value of , table position of deleted data: n
*3. m = (Number of data tables) - (Table position of data insertion)
Number of data tables: Present value of , table position data insertion: n
Data comparison
220 ⎯⎯ ⎯ ⎯ ⎯
221 ⎯⎯ ⎯ ⎯ ⎯
222 ⎯⎯ ⎯ ⎯ ⎯
223 ⎯⎯ ⎯ ⎯ ⎯
224 LD= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
225 LD> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
226 LD< 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
227 ⎯⎯ ⎯ ⎯ ⎯
228 LD<> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
229 LD<= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
230 LD>= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
231 ⎯⎯ ⎯ ⎯ ⎯
232 AND= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
233 ADN> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
234 AND< 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
235 ⎯⎯ ⎯ ⎯ ⎯
236 AND<> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
FNC
No.
Instruction
Execution time in ON status (µs) Execution time in OFF status (µs)
Remarks
16-bit instruction 32-bit instruction 16-bit instruction 32-bit instruction
D
D
