Mitsubishi FX3U Series Programming Manual

916
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
B Instruction Execution Time
B-4 Applied Instruction Execution Time
Data comparison
237 AND<= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
238 AND>= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
239 ⎯⎯ ⎯ ⎯ ⎯
240 OR= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
241 OR> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
242 OR< 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
243 ⎯⎯ ⎯ ⎯ ⎯
244 OR<> 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
245 OR<= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
246 OR>= 1.22 1.48 1.22 1.48
For details, refer to
Appendix B-6-2.
247 ⎯⎯ ⎯ ⎯ ⎯
248 ⎯⎯ ⎯ ⎯ ⎯
249 ⎯⎯ ⎯ ⎯ ⎯
Data table processing
250 ⎯⎯ ⎯ ⎯ ⎯
251 ⎯⎯ ⎯ ⎯ ⎯
252 ⎯⎯ ⎯ ⎯ ⎯
253 ⎯⎯ ⎯ ⎯ ⎯
254 ⎯⎯ ⎯ ⎯ ⎯
255 ⎯⎯ ⎯ ⎯ ⎯
256 LIMIT 8.1 8.6 0.585 1.105
257 BAND 8.1 8.6 0.585 1.105
258 ZONE 7.9 8.5 0.585 1.105
259 SCL 15.9 16.8 0.455 0.845
260 DABIN 13.7 19.5 0.325 0.585
261 BINDA 16.7 23.1 0.325 0.585
262 ⎯⎯ ⎯ ⎯ ⎯
263 ⎯⎯ ⎯ ⎯ ⎯
264 ⎯⎯ ⎯ ⎯ ⎯
265 ⎯⎯ ⎯ ⎯ ⎯
266 ⎯⎯ ⎯ ⎯ ⎯
267 ⎯⎯ ⎯ ⎯ ⎯
268 ⎯⎯ ⎯ ⎯ ⎯
269 SCL2 2.79 + 5.21n 29.06 + 7.94n 0.455 0.845 n: Number of data
External device communication (inverter communication)
270 IVCK 24.5 ⎯ 6.5 ⎯
271 IVDR 22.7 ⎯ 6.5 ⎯
272 IVRD 26.8 ⎯ 6.5 ⎯
273 IVWR 24.7 ⎯ 6.5 ⎯
274 IVBWR 31.0 ⎯ 6.5 ⎯
275 IVMC 29.6 ⎯ 6.5 ⎯
FNC
No.
Instruction
Execution time in ON status (µs) Execution time in OFF status (µs)
Remarks
16-bit instruction 32-bit instruction 16-bit instruction 32-bit instruction
