917
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
B Instruction Execution Time
B-4 Applied Instruction Execution Time
31
FNC276-FNC279
Data
Transfer 3
32
FNC280-FNC289
High-Speed
Processing 2
33
FNC290-FNC299
Extension File
Register
34
FNC300-FNC305
FX
3U
-CF-ADP
35
SFC•STL
Programming
36
Interrupt
Function
37
Special Device
38
Error Code
A
Version Up
Information
B
Execution Times
Data move 3
276 ⎯⎯ ⎯ ⎯ ⎯
277 ⎯⎯ ⎯ ⎯ ⎯
278
RBFM
*1
50+900n ⎯ 0.715 ⎯
n :
Number of points transferred in
one operation cycle
RBFM
*2
244 + 103n ⎯ 0.715 ⎯
279
WBFM
*1
24 + 966n ⎯ 0.715 ⎯
n :
Number of points transferred in
one operation cycle
WBFM
*2
292 + 116n ⎯ 0.715 ⎯
*1. When the instruction is executed to a BFM in a special function block/unit for the FX0N/FX2N/FX2NC Series or
in the CC-Link/LT built in the FX3UC-32MT-LT(-2)
*2. When the instruction is executed to a BFM in a special function block/unit for the FX3U/FX3UC Series
High-speed processing 2
280 HSCT ⎯ 30.0 ⎯ 1.365
281 ⎯⎯ ⎯ ⎯ ⎯
282 ⎯⎯ ⎯ ⎯ ⎯
283 ⎯⎯ ⎯ ⎯ ⎯
284 ⎯⎯ ⎯ ⎯ ⎯
285 ⎯⎯ ⎯ ⎯ ⎯
286 ⎯⎯ ⎯ ⎯ ⎯
287 ⎯⎯ ⎯ ⎯ ⎯
288 ⎯⎯ ⎯ ⎯ ⎯
289 ⎯⎯ ⎯ ⎯ ⎯
Extension file register control
290 LOADR 13.2 + 0.44n ⎯ 0.325 ⎯
291 SAVER 166n ⎯ 6.4 ⎯
292 INITR 17600n ⎯ 0.325 ⎯
293 LOGR 244 + 17.9n ⎯ 0.715 ⎯
294 RWER 46700n ⎯ 0.325 ⎯
n : Number of write target
sectors
295 INITER 17300n ⎯ 0.325 ⎯
296
to
299
⎯⎯ ⎯ ⎯ ⎯
FX3U-CF-ADP
300 FLCRT 83.2 ⎯ 6.64 ⎯
301 FLDEL 49.1 ⎯ 6.32 ⎯
302 FLWR 77.9 + 2.9n ⎯ 6.26 ⎯
n : Number of written data
points
*3
303 FLRD 59.2 + 4.25n ⎯ 6.18 ⎯
n : Number of read data
points
*3
304 FLCMD 50.9 ⎯ 6.26 ⎯
305 FLSTRD 50.9 ⎯ 6.24 ⎯
*3. When 16-bit data is written or read.
FNC
No.
Instruction
Execution time in ON status (µs) Execution time in OFF status (µs)
Remarks
16-bit instruction 32-bit instruction 16-bit instruction 32-bit instruction
To Next Page
