With AC Input type modules, it is recommended that the same supply voltage to the PLC is
used as for the inputs (i.e. 100 –120 V AC). This minimises the possibility of an incorrect volt-
age being connected to the inputs.
MELSEC System Q Beginners Manual 3 – 23
Digital Input and Output Modules Das MELSEC System Q
100
90
80
70
60
50
40
01020304050
55
120 V AC
132 V AC
%
For the module QX10, the number of inputs
which can be switched on simultaneously,
depends on the ambient temperature.
Ambient temperature [쎶C]
ON ratio
1
0
3
5
7
9
B
D
F
2
4
6
8
A
C
E
NC
100VDC
8mA60Hz
7mA50Hz
COM
F
E
D
C
B
A
9
8
7
6
5
4
3
2
1
0
QX10
01234567
89ABC D EF
LED
1
16
17
100 - 120 V AC
Input module
Internal circuit
Opto-coupler
Appearance Circuit Diagram Terminal Signal
1 X00
2 X01
3 X02
4 X03
5 X04
6 X05
7 X06
8 X07
9 X08
10 X09
11 X0A
12 X0B
13 X0C
14 X0D
15 X0E
16 X0F
17 COM
18 Vacant
