Transistor Output Modules
As with all other output configurations the physical outputs of transistor output modules are
isolated by opto-coupler.
Response of the transistor in either direction is only 1 ms at 24 V DC, 200 mA. The exact cur
-
rent handling capacity of each output is specified in the relevant hardware manual.
For the MELSEC System Q transistor output modules are available in sink and source
configuration.
Example for a source transistor output module
3–28 MITSUBISHI ELECTRIC
Das MELSEC System Q Digital Input and Output Modules
Item Specifications
Type of module QY80
Number of output points 16
Isolation method Opto-coupler
Rated switching voltage 12 to 24 V DC (+20/-15%)
Switching voltage range 10.2 to 28.8 V DC
Maximum load current 0.5 A per output, 4 A per group
Maximum inrush current 4 A for 10 ms
Leakage current at OFF 0.1 mA or less
Maximum voltage drop at ON 0.2 V DC @ 0.5 A (TYP), maximum 0.3 V @0.5 A
Response time
OFF 씮 ON 1 ms or less
ON 씮 OFF 1 ms or less (rated load, resistive load)
Surge suppressor Zener diode
Fuse 6.7 A (unchangeable)
Fuse blow indication LED indicates blown fuse and an signal is issued to the PLC CPU
External power
supply
Voltage 12 to 24 V DC (+20/-15%, ripple ratio within 5%)
Current 20 mA (at 24 V DC and when all outputs are ON)
Dielectric withstand voltage 560 V AC rms/3 cycles (altitude: 2000 m)
Insulation resistance 10 M⏲ or more (by insulation resistance tester)
Noise immunity
By noise simulator of 500 V p-p noise voltage, 1애s noise width and 25 to
60 Hz noise frequency
First transient noise IEC61000-4-4: 1kV
Groups of outputs 1 group with 16 outputs (Common terminal: terminal 17)
Operation indicator 1 LED for each output
External connections 18-point terminal block (M3 x 6 screws)
Applicable wire size 0.3 to 0.75 mm
2
, core: 2.8 mm OD max.
Internal current consumption
(5 V DC)
80 mA (When all outputs are switched ON.)
Weigth 0.17 kg
