Mitutoyo MF Series User Manual

No. 99MBA091A
1-16
○ Halogen control unit
ｂ）AC inlet
Connect the power cord.
ｃ）DIN connector 1 for external light
This connector is not used.
ｄ）DIN connector 2 for external light
This connector is not used.
ｅ）Connector for control cable
This connector is used to connect this unit and the cable connected to the control
unit.
ｆ）USB connector
This connector is not used.
ｇ）Connector for vertical reflected illuminator (halogen)
This connector is used to connect a halogen type transmitted illuminator.
ｈ）Connector for transmitted illuminator (halogen)
This connector is used to connect a halogen type transmitted illuminator.
b) AC inlet
d) DIN connector 2 for
external light
c) DIN connector 1
for external light
e) Connector for control
cable
f) USB connector
h) Connector for
transmitted illuminator
(halogen)
g) Connector for vertical
reflected illuminator
(halogen)
