6.7.5 Connecting DPU-414 (Printer)
（1）Software DIP SW 1-3 setting
Notice：Do not turn off power while during start up setting. (The procedure cannot be skipped.)
Remark：Set the [FEED] key off, and the [ON LINE] key on.
Key operation Contents of printout Remarks
Turn the power switch “ON” pressing
the [ON LINE] key
Automatically print the present
DPU-414 setting. At the last
line, the prompts are printed as
below:
Continue ? :Push ‘On-line SW’
Write ?:Push ‘Paper feed SW’
Start startup setting
[ON LINE] Dip SW-1 Setting of SW1
[FEED] [ON LINE] [ON LINE] [FEED]
[ON LINE] [FEED] [ON LINE] [ON
LINE]
(off)(on)(on)(off)
(on)(off)(on)(on)
Continue ? :Push ‘On-line SW’
Write ?:Push ‘Paper feed SW’
Input method: Serial
CR＝CR
Printing density
＝100％
[ON LINE] Dip SW-2 Setting of SW2
[ON LINE] [ON LINE] [ON LINE] [ON
LINE]
[ON LINE] [ON LINE] [ON LINE] [ON
LINE]
(on)(on)(on)(on)
(on)(on)(on)(on)
Continue ? :Push ‘On-line SW’
Write ?:Push ‘Paper feed SW’
Normal printing
(40 columns)
Japanese
[ON LINE] Dip SW-3 Setting of SW3
[FEED] [FEED] [FEED] [FEED]
[FEED] [ON LINE] [ON LINE] [ON
LINE]
(off)(off)(off)(off)
(off)(on)(on)(on)
Continue ? :Push ‘On-line SW’
Write ?:Push ‘Paper feed SW’
Data bit length: 7 bits
Parity permission:
Even number
Baud rate: 9600 bps
[FEED] Dip SW setting complete!! Complete setting
（2）Printing operation
1) Turn on the “ON LINE” lamp by pressing the [ON LINE] key, then start printing with the MF foot
switch (option).
2) Turn off the “ON LINE” lamp by pressing the [ON LINE] key, then press the [FEED] key to feed
paper.
3) Turn the power switch “ON” pressing the [FEED] key to start test printing.
