No. 99MBA091A
5-4
5.4 Error Messages and Remedies
5.4.1 Counter and concerned matters
LED display
Meaning and remedy
Overspeed arising；Traverse speed of the axis which displayed the error is
too fast.
･･･
Press the zero-set button of the axis which displayed the error or restart
the microscope main unit.
Overcount arising；The scale of the axis which displayed the error exceeds
the possible counting range.
･･･
Return the scale of the axis which displayed the error to the possible
counting range or restart the microscope main unit.
RS232C parity error
･･･
Press the X-axis zero-set button or send C0 (zero) command by RS-232C
from peripheral devices such as PC. Restart both of the peripheral devices
and the microscope main unit when the communication is not resumed.
RS232C over-run error
･･･
Press the X-axis zero-set button or send C0 (zero) command by RS-232C
from peripheral devices such as PC. Restart both of the peripheral devices
and the microscope main unit when the communication is not resumed.
RS232C framing error
･･･
Press the X-axis zero-set button or send C0 (zero) command by RS-232C
from peripheral devices such as PC. Restart both of the peripheral devices
and the microscope main unit when the communication is not resumed.
TIP
When an error code has been cleared (power is turned on), the counter displays
all zeros. Perform measurement from the start.
