1. Overview
No. 99MBA091A
1-15
1.2.5 Illuminator unit
24） LED control unit: Controls the lighting of the LED illuminator.
25） Halogen control unit: Controls the lighting of the halogen illuminator.
① Front panel of control unit (common to LED/halogen
ａ）Main power switch
This switch is used to supply power to the whole system.
NOTE
To shut off the power completely, turn off the main power switch.
② Rear panel of control unit
○ LED control unit
a) Main power switch
b) AC inlet
d) DIN connector 2 for external light
c) DIN connector 1 for
external light
e) Connector for control
cable
f) USB connector
