No. 99MBA091A
4-2
4.3 Replacing Consumables
The halogen bulb and stage glass are consumables and need to be replaced. Follow the
replacement procedure described in the instructions in safety.
4.3.1 Replacing halogen bulbs
(1) Turn off the power to the system.
(2) Allow a sufficient period of time for the bulb to cool.
IMPORTANT
The bulbs and the peripherals stay hot for a period after use. Be sure to perform
the above procedures and check that the bulbs have cooled, then proceed to the
next step.
(3) Turn off the power switch and pull out the power cord.
IMPORTANT
Serious injury and risk of electrocution will result if cover is opened while power
is on.
(4) Loosen and remove two fixing screws for the head cover of illuminator (cross
recessed pan head screws) by a supplied Philips screw driver.
Fixing screws for
head cover
Head cover
To Next Page
