4. Maintenance
No. 99MBA091A
4-3
(5) Pull straight the old bulb, and then insert the new one into the socket. Do not touch the
bulb directly with the bare hand, otherwise the glass surface is contaminated with the
oil etc., resulting in the short life of the bulb.
Insert the bulb all the way until it reaches the end of the socket. If not inserted well
enough, uniform illumination can not be obtained.
IMPORTANT
Use only the specified halogen bulbs.
Unspecified halogen bulb may prevent the machine from performing efficiently.
TIP
For information about the halogen bulbs type, refer to "6.3 List of Consumable".
To Next Page
