Mitutoyo SURFTEST SV-3100 User Manual

1.2 Order No. and specifications
This system comes with different basic specifications depending on the Order No.
The following table shows the specifications of the measuring main unit, the unit system,
and the applicable voltage for each Order No.
Table 1-1 SV-3100 series ( The model without X axis inclination unit)
Order No. Model name
Z1 axis detector
Measurement
force
X-axis
stroke
Z2-axis
stroke
Base size
Unit System
(Calibration Kit)
Applicable
Voltage (V)
178-451A/C -1 100 series
178-451D/E/DC/K -1
mm
200 series
178-461A -1 100 series
178-461D/E/DC -1
SV-3100S4 300mm
inch
200 series
178-452A/C -1 100 series
178-452D/E/DC/K -1
mm
200 series
178-462A -1 100 series
178-462D/E/DC -1
SV-3100H4
600x450
mm
inch
200 series
178-453A/C -1 100 series
178-453D/E/DC/K -1
mm
200 series
178-463A -1 100 series
178-463D/E/DC -1
SV-3100W4
100mm
500mm
1000x450
mm
inch
200 series
178-456A/C -1 100 series
178-456D/E/DC/K -1
mm
200 series
178-466A -1 100 series
178-466D/E/DC -1
SV-3100S8 300mm
inch
200 series
178-457A/C -1 100 series
178-457D/E/DC/K -1
mm
200 series
178-467A -1 100 series
178-467D/E/DC -1
SV-3100H8
600x450
mm
inch
200 series
178-458A/C -1 100 series
178-458D/E/DC/K -1
mm
200 series
178-468A -1 100 series
178-468D/E/DC -1
SV-3100W8
0.75mN
No.178-396-2
200mm
500mm
1000x450
mm
inch
200 series
178-451A/C -2 100 series
178-451D/E/DC/K -2
mm
200 series
178-461A -2 100 series
178-461D/E/DC -2
SV-3100S4 300mm
inch
200 series
178-452A/C -2 100 series
178-452D/E/DC/K -2
mm
200 series
178-462A -2 100 series
178-462D/E/DC -2
SV-3100H4
600x450
mm
inch
200 series
178-453A/C -2 100 series
178-453D/E/DC/K -2
mm
200 series
178-463A -2 100 series
178-463D/E/DC -2
SV-3100W4
100mm
500mm
1000x450
mm
inch
200 series
178-456A/C -2 100 series
178-456D/E/DC/K -2
mm
200 series
178-466A -2 100 series
178-466D/E/DC -2
SV-3100S8 300mm
inch
200 series
178-457A/C -2 100 series
178-457D/E/DC/K -2
mm
200 series
178-467A -2 100 series
178-467D/E/DC -2
SV-3100H8
600x450
mm
inch
200 series
178-458A/C -2 100 series
178-458D/E/DC/K -2
mm
200 series
178-468A -2 100 series
178-468D/E/DC -2
SV-3100W8
4mN
No.178-397-2
200mm
500mm
1000x450
mm
inch
200 series
No. 99MBB187A
1-2
