2. Basic Knowledge
3.6 Setting the Stylus Information
Various types of styli are prepared for measurement. Depending on the selected
combination, the reading will differ even if an identical displacement is given.
Therefore, to avoid errors, it is necessary to determine the type of arm and stylus to
be used and their mounting directions in advance.
Perform this setup with the following procedure.
1. Open the Setup screen
Click on [Set Machine…] in the [Setup] menu on the toolbar.
Click on this.
No. 99MBA040A
3-5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
To Next Page
