Mitutoyo SURFTEST SV-3100 User Manual

1.3 Name and Function of Each Part
This section describes the name and function of each part.
1.3.1 System configuration
The SURFTEST SV-3100 series consists of the following system units.
Fig. 1-1
3. Remote box
5. Ink-jet printer
set
1-1.Z1-axis
detector
4.Data processing
2. Controller
1. Measurin
g
main unit
/analysis unit
1. Measuring main unit
1-1 Z1-axis detector
2. Controller
3. Remote box
4. Data processing/analysis unit: Surface roughness Analysis Program has been
preinstalled.(Option)
5. Ink-jet printer set (Option)
CAUTION
The measuring main unit is a drive machine under motor-driven control. To use this main
unit safely, be sure to read “Safety Precautions” in this manual prior to use. Observe all
precautions.
No. 99MBB187A
1-4
