Mitutoyo SURFTEST SV-3100 - Roughness Measuring Detector (S-3000)

1. CONFIGURATION
1.3.3 Roughness measuring detector (S-3000)
This subsection describes the name and function of each part on the roughness
measuring detector (S-3000).
The roughness measuring detector (S-3000) consists of the roughness detector and
detector holder unit.
Fig. 1-4
1. Roughness detector
Fig. 1-5
1-1. Detector main unit
1-2. Safety nosepiece
Used for protecting a stylus.
1-1. Detector main unit
1-4. Skidless
nose
p
iece
1-2. Safety nosepiece
1-3. Standard stylus
1. Roughness detector
2. Detector holder unit
No. 99MBB187A
1-9
