Warning Labels
The Mitutoyo SURFTEST SV-3100 series has been designed and manufactured with
human safety taken as a major consideration. However, in order that it may be used more
safely, warning labels have been applied to the main unit and all peripheral devices. This
section describes the label application places and warning contents. Before operating the
SURFTEST SV-3100 series be sure to read this section along with each chapter to use it
safely for an extended period of service life.
Measuring Main Unit
H
E C
G
B
F
D
A
Description of SURFTEST Warning Labels
<<Be careful of fingers>>
Notifies the operator of the risk of injury due to pinched fingers.
A: When the Z-axis detector feeds in the Z-axis direction, do not allow your head
or hands to go between the detector and base, or they may be caught.
B: When the Z-axis detector feeds in the X-axis direction, do not allow your head
or hands to go between the detector and X-axis cover, or they may be caught.
C, D, E, F: When the X-axis unit feeds in the Z-axis direction, do not allow your
head or hands to go between the slotted hole on the side surface of the column
and the slider, or they may be caught.
No. 99MBB187A
