4. Dust
This system consists of high-precision components such as the guide surface of each unit
and length measurement unit, etc., that may be affected by dust. So, use this system in a
place where it is as free from dust as possible.
5. Power supply
For supplying power to this system prepare an outlet rated to 100V-200VAC + 10%/- 5%,
50/60 Hz (grounded, and applicable to 2-prong type plug). The supplied power should
have a sufficient margin over the system consumption rate.
Table 2-1 shows the power consumption of this system.
Table 2-1
Distribution method Single phase, 2-wire. One wire is grounded.
Voltage 100V-240VAC +10%/-5%
Frequency 50/60 Hz
Grounding Class D grounding or better
Controller Max.400 VA
Computer Max.240 VA
Display Max.200 VA
Power
dissipation
Printer Max.620 VA
Number of outlets 4 places
TIP
•The supplied power will differ depending on the computer, display, and printer
models used. For exact specifications refer to each operation manual of the
computer, display, and printer to be used.
CAUTION
• Use the outlet provided in the installation site exclusively for this system, and do
not share it with other power equipment. For information about the power supply
of the computer and other control units, refer to the operation manual of each
piece of equipment.
No. 99MBB187A
2-2
