10 TECHNICAL DATA
10.1 Technical Features
The basic technical specifications can be found on the hoist’s data plate. In this chapter you can
see more extensive technical specifications.
Technical data
Load
1000 KG
Height of lift
25 M
Power supply
3-phase (EL17) / 400 V (ELE01) / 50 HZ (ELE03)
Hoisting
speed
4 m/min (SPD03)
10.2 Tightening torques
The recommended tightening torques for steel are presented in the following table
NOTICE
Values shown in the table are nominal values. In practice, for example
for lubricated bolts, you need to use higher torques.
Tightening torque
Bolt size
Strength 8.8
Strength 10.9
[N m]
[Ft lb]
[N m]
[Ft lb]
M4
2.7
2.0
4.0
2.9
M5
5.4
4.0
7.9
5.8
M6
9.3
6.8
14
10.3
M8
23
17.0
33
24
M10
45
33.0
66
48.5
M12
77
56.6
115
84.6
M14
125
92
180
132
M16
190
140
280
206
M18
275
202
390
287
M20
385
283
550
404
M22
530
390
750
552
M24
660
485
950
699
M27
980
721
1400
1030
M30
1350
993
1900
1398
Note: It is recommended that self-locking nuts are always replaced when
removed. Self locking nuts can be reused no more than 5 times.
