Monarch SE 2004 - Cooktop

168 | Section 4 Appliances ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ ----------------- Monarch SE 2004
The cooktop uses LP-Gas only as a fuel
source. The burners use a piezo type igniter. The
cooktop should be used for cooking purposes
only and not as a heating source. When the
burner valve is opened the fuel source flows
through the valve into the mixture tube. The fuel
passes by a hole or venturi in the mixture tube,
which draws air in with the fuel for a proper
fuel/air ratio. The flame should have a blue
appearance with a lighter blue defined flame at
the burner head. A yellow flame or yellow tips
indicate a rich fuel mixture, which can leave a
black color or carbon on the bottom of a pot or
pan.
The cooktop will operate when the following
conditions are met:
1. The primary LP-Gas valve on the LP tank
is open.
2. The battery cut-off switch is on.
Before cooking on the range top the cover
must be in full upright and folded position. Push
the cover toward the outside wall and lock it into
position to prevent it from falling onto the range
top during cooking.
To Lift Cover:
• Lift the cover then fold. The cover will
engage the lock when placed into the full
upright position.
CAUTION: The cover is very
heavy.
To Close Cover:
• Allow the cooktop to cool to room
temperature before closing cover.
Raise cover arms from lock position,
lower and unfold cover.
COOKTOP
030996
030869
