Monarch SE 2004 - Workhorse Chassis

Monarch SE 2004-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Section 8 Electrical System | 305
Workhorse Chassis
WORKHORSE FUSES & CIRCUIT BREAKERS
Name
Circuit Protected Fuse Circuit Breaker
HTR
Circuit Protected 25A N/A
PWR
Not Used By Body Manufacturer N/A 30A
HORN/DM
Not Used By Body Manufacturer 20A
ACC Radio Accessory and W iper Motor Feed N/A 10A
TURN-B/U
Turn Signal Flasher, PARK/NEU
POSN & B/U LP SW
15A N/A
ECM-BAT
Fuel Pump Relay, Engine Oil
Pressure IND Sensor, Vehicle
Control Module
20A N/A
TAIL LPS
Head Lamp Switch 20A N/A
GAUGES
DTL Relay & Control Module, AC
Compressor Relay, Instrument
Panel Cluster, Audio Alarm,
Alternator, Ignition Feed
20A N/A
I-3
Cruise Control Module & Switch,
Vehicle Control Module, Stop
Lamp/TCC Switch, ABS Module
15A N/A
ENG-BAT
AC Compressor Relay, Data link 15A N/A
STOP-HAZ
Hazard Lamp Flasher, Stop Lamp
Switch
15A N/A
ECM-I
Fuel Injectors, Ignition Coil,
Electronic Ignition Control Module,
Vehicle Control Module,
Crankshaft Position Sensor,
Instrument Panel Cluster
20A N/A
AUX
Not Used By Body Manufacturer N/A 30A
WIPER
Not Used By Body Manufacturer 25A N/A
ENG-I
Sensors, Mass Air Flow Sensor,
Vehicle Control Module, EGR
Valve Solenoid Evaporative
Emissions Canister Purge Valve
Solenoid, Fan Control Relay
20A N/A
INS TR-LP S
Audio Alarm, PRNDL Lamp,
Instrument Panel Cluster,
Manufacturer Instrument Lamps
5A N/A
TRANS
Transmission 10A N/A
CRANK
Starter Relay 10A N/A
AUTO APPLY
Park Brake Low Pressure Switch,
Auto Apply Park Brake Switch
10A N/A
