Monarch SE 2004 - Slide-Out Cover

202 | Section 5 Equipment -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------- Monarch SE 2004
The slide-out cover is automatic. When the slide-out moves in or out, the cover
reacts to the slide-out direction. A fixed edge of the slide-out cover is installed into
an awning rail, mounted just above the slide-out. A spring-loaded roller with
special brackets mounts to the slide-out. In a hard rain, the cover helps prevent
water from penetrating the seal of the slide-out.
The slide-out cover will extend automatically attaining full coverage when the
slide-out achieves maximum extension.
NOTE: Water may pool on top of the extended cover. As the slide-out is
retracted, the water is removed when the cover retracts. Retract room
slowly. Pause three or four times to allow any accumulated water a
chance to run off.
The slide-out cover retracts automatically and rolls up to the travel position
when the slide-out is completely closed.
NOTE: When retracting the slide-out, stop the room approximately
halfway. Confirm that the fabric is rolling properly before fully
retracting the slide-out.
Slide-Out Cover
030924B
