TIRE CHARTS -
Michelin
225/70R19.5 LRF (2) XRV
PSI 70 75 80 85 90 95
lbs per
position
S 2895 3040 3195 3315 3450 3640
D 5440 5720 6000 6230 6490 6830
*kg. per
position
S 1313 1379 1450 1503 1565 1650
D 2467 2595 2722 2826 2944 3100
245/70R19.5 LRF - XRV
PSI 70 75 80 85 90 95
lbs per
position
S 3440 3540 3640 3740 3890 4080
D 6430 6630 6830 7030 7310 7720
*kg. per
position
S 1560 1605 1651 1697 1764 1850
D 2916 3007 3098 3189 3316 3500
One Kilogram = 2.2 lbs.
GoodYear
TIRE
SIZE
MAX
Speed
Rating
(MPH)
Dual
(D)
Single
(S)
Inflation Pressure PSI
245/70R19.5 75
D
S
65 70 75 80 85 90 95 100
--
--
3415
3640
3515
3740
3655
3890
3875(F)
4080 (F)
3940
4190
4075
4335
4375 (G)
4545 (G)
Use the tire chart to locate the recommended air pressure for the weight carried
by each tire. A quality truck tire gauge with an angle dual head is recommended.
Adjust the tire pressure accordingly.
Understanding the Inflation Table
• Tire Size is on the left margin of the Table.
• Determine the "Single" inflation reading or "Dual" inflation reading.
This is denoted with a "D" or "S" on the Table. Single is for the Front
axle. Dual is for the Drive axle.
• Find the corresponding psi at the top columns to see the corresponding
maximum weight capacity for that psi.
