Monarch SE 2004-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Section 4 Appliances | 177
Separate thermostats are used for LP-Gas and AC electric. The thermostat
controls the power to the module board. At 130° F, the thermostat will open,
extinguishing the burner. If the thermostat fails, a High Temperature safety limit
switch will open. The safety switch will require manual reset.
CAUTION: If the High Temperature safety limit should open,
discontinue using the water heater. Have the water heater
inspected by a qualified technician to determine the cause of the
over temperature condition.
The bypass valve is located at the back of the water heater. Turning the valve to
BYPASS stops water from entering the cold water inlet of the water heater. Turn
the valve to BYPASS when winterizing. For normal operation, turn valve so that
handle points to NORMAL FLOW.
Thermostats
Water Heater
Bypass
040493C
