Motorola ASTRO Digital XTL 5000 Detailed Service Manual

7-164 Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board
May 25, 2005 6881096C74-B
C0505 2113743L41 CAP CHIP 10000 PF 10% X7R
C0506 2113743L41 CAP CHIP 10000 PF 10% X7R
C0507 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0510 2185802B01 CAP 10V 4.7UF
C0512 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0513 2311049A43 CAP TANT CHIP 150 10 6
C0514 2311049A43 CAP TANT CHIP 150 10 6
C0515 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0516 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0517 2185802B01 CAP 10V 4.7UF
C0518 2185802B01 CAP 10V 4.7UF
C0519 2113743L41 CAP CHIP 10000 PF 10% X7R
C0520 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0521 2185802B01 CAP 10V 4.7UF
C0522 2185802B01 CAP 10V 4.7UF
C0523 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0524 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0525 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0526 2113743L41 CAP CHIP 10000 PF 10% X7R
C0527 2185802B01 CAP 10V 4.7UF
C0528 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0529 2185802B01 CAP 10V 4.7UF
C0531 2113741N69 CAP CHIP CL2 X7R 10%
100000
C0532 2113741Y32 CAP CER 1,000,000 10% 50V
C0533 2311049C47 CAP TANT CHIP 22.0UF 10%
16V
C0534 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0535 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0600 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0601 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
Reference
Designator
Motorola
Part Number
Description
C0603 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0604 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0605 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0606 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0610 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0611 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0613 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0614 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0615 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0616 2113743N50 CAP CHIP 100 PF 5% COG
C0700 2113743N50 CAP CHIP 100 PF 5% COG
C0701 2113743N50 CAP CHIP 100 PF 5% COG
C0702 2113743N50 CAP CHIP 100 PF 5% COG
C0703 2113743N50 CAP CHIP 100 PF 5% COG
C0704 2113743N50 CAP CHIP 100 PF 5% COG
C0705 2113743N50 CAP CHIP 100 PF 5% COG
C0706 2113743N50 CAP CHIP 100 PF 5% COG
C0708 2113743N50 CAP CHIP 100 PF 5% COG
C0709 2113743N50 CAP CHIP 100 PF 5% COG
C0710 2113743N50 CAP CHIP 100 PF 5% COG
C0711 2113743N50 CAP CHIP 100 PF 5% COG
C0712 2113743N50 CAP CHIP 100 PF 5% COG
C0713 2113743L01 CAP CHIP 220 PF 10% X7R
C0714 2113743L01 CAP CHIP 220 PF 10% X7R
C0715 2113743N50 CAP CHIP 100 PF 5% COG
C0722 2113743A31 CAP CHIP 1.0 UF 10% X7R
C0724 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0729 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0900 2113743L17 CAP CHIP 1000 PF 10% X7R
C0901 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0902 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
Reference
Designator
Motorola
Part Number
Description
C0903 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0904 2113743L01 CAP CHIP 220 PF 10% X7R
C0905 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0906 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0907 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0908 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0909 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0910 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0911 2113743N50 CAP CHIP 100 PF 5% COG
C0912 2113743N50 CAP CHIP 100 PF 5% COG
C0913 2113743N50 CAP CHIP 100 PF 5% COG
C0915 2113743N50 CAP CHIP 100 PF 5% COG
C0918 2113743N50 CAP CHIP 100 PF 5% COG
C0919 2113743N50 CAP CHIP 100 PF 5% COG
C0920 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0922 2113743N50 CAP CHIP 100 PF 5% COG
C0930 2113743N50 CAP CHIP 100 PF 5% COG
C0933 2113743N50 CAP CHIP 100 PF 5% COG
C0934 2113743N50 CAP CHIP 100 PF 5% COG
C0935 2113743N50 CAP CHIP 100 PF 5% COG
C0936 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0937 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0940 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0941 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
C0942 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
C0943 2113743L41 CAP CHIP 10000 PF 10% X7R
C0944 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0945 2185802B01 CAP 10V 4.7UF
C0950 2113741N69 CAP CHIP CL2 X7R 10%
100000
C0951 2113741Y32 CAP CER 1,000,000 10% 50V
Reference
Designator
Motorola
Part Number
Description
C0952 2113743E20 CAP CHIP .10 UF 10%
C0953 2311049C47 CAP TANT CHIP 22.0UF 10%
16V
C0954 2113743E20 CAP CHIP .10 UF 10%
C0955 2113741N69 CAP CHIP CL2 X7R 10%
100000
C0956 2311049C06 CAP TANT CHIP 22 UF 35V
20%
C0957 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0959 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0960 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0961 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0963 2113743N50 CAP CHIP 100 PF 5% COG
C0964 2113743N50 CAP CHIP 100 PF 5% COG
C0965 2113743N50 CAP CHIP 100 PF 5% COG
C0966 2113743N50 CAP CHIP 100 PF 5% COG
C0968 2113743N50 CAP CHIP 100 PF 5% COG
C0969 2113743N50 CAP CHIP 100 PF 5% COG
C0970 2113743N50 CAP CHIP 100 PF 5% COG
C0972 2113743E20 CAP CHIP .10 UF 10%
C0973 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0974 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0975 2113743N50 CAP CHIP 100 PF 5% COG
C0976 2113743N50 CAP CHIP 100 PF 5% COG
C0978 2113743N50 CAP CHIP 100 PF 5% COG
C0979 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0980 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0981 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0982 2311049C47 CAP TANT CHIP 22.0UF 10%
16V
C0983 2113743N50 CAP CHIP 100 PF 5% COG
C0984 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0985 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
Reference
Designator
Motorola
Part Number
Description
