Motorola ASTRO Digital XTL 5000 Detailed Service Manual

Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board 7-165
6881096C74-B May 25, 2005
C0986 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0987 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0989 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0990 2113743L50 CAP CHIP 33000 PF 10%
C0991 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0997 2113740F47 CAP CHIP REEL CL1 +/-30 68
C0998 2113741F01 CAP CHIP CL2 X7R REEL 100
C5001 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5002 2113743N28 CAP CHIP 12.0 PF 5% COG
C5003 2113743L41 CAP CHIP 10000 PF 10% X7R
C5004 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5005 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5006 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5007 2113743N30 CAP CHIP 15.0 PF 5% COG
C5008 2113743L25 CAP CHIP 2200 PF 10% X7R
C5009 2113740F58 CAP CHIP REEL CL1 +/-30
200
C5010 2113743N50 CAP CHIP 100 PF 5% COG
C5011 2113743F18 CAP CHIP 2.2 UF 16V +80-
20%
C5012 2113743N50 CAP CHIP 100 PF 5% COG
C5013 2113743N50 CAP CHIP 100 PF 5% COG
C5014 2113743L41 CAP CHIP 10000 PF 10% X7R
C5015 2113743L41 CAP CHIP 10000 PF 10% X7R
C5017 2113743L41 CAP CHIP 10000 PF 10% X7R
C5018 2113743T19 CAP 10UF 16V CER 3225 X5R
C5019 2113743N50 CAP CHIP 100 PF 5% COG
C5020 2113743L17 CAP CHIP 1000 PF 10% X7R
C5021 2113743L41 CAP CHIP 10000 PF 10% X7R
C5022 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5023 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5025 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
Reference
Designator
Motorola
Part Number
Description
C5026 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5030 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5032 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5033 2113743N52 CAP CHIP 120 PF 5% COG
C5034 2113743N40 CAP CHIP 39.0 PF 5% COG
C5037 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5039 2113743N29 CAP CHIP 13.0 PF 5% COG
C5040 2113743L41 CAP CHIP 10000 PF 10% X7R
C5041 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5044 2113743A19 CAP CHIP .100 UF 10% X7R
C5045 2113743A31 CAP CHIP 1.0 UF 10% X7R
C5048 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5050 2113743T19 CAP 10UF 16V CER 3225 X5R
C5051 2113743L17 CAP CHIP 1000 PF 10% X7R
C5052 2113743L17 CAP CHIP 1000 PF 10% X7R
C5056 2113743N34 CAP CHIP 22.0 PF 5% COG
C5057 2113743N30 CAP CHIP 15.0 PF 5% COG
C5058 2113743L17 CAP CHIP 1000 PF 10% X7R
C5059 2113743N36 CAP CHIP 27.0 PF 5% COG
C5060 2113743L01 CAP CHIP 220 PF 10% X7R
C5061 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5062 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5063 2113743A31 CAP CHIP 1.0 UF 10% X7R
C5064 2113743L41 CAP CHIP 10000 PF 10% X7R
C5065 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5066 2113743L17 CAP CHIP 1000 PF 10% X7R
C5067 2113743N50 CAP CHIP 100 PF 5% COG
C5068 2113743N50 CAP CHIP 100 PF 5% COG
C5069 2113743N54 CAP CHIP 150 PF 5% COG
C5070 2113743N50 CAP CHIP 100 PF 5% COG
C5071 2113743N30 CAP CHIP 15.0 PF 5% COG
C5072 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5073 2113743A31 CAP CHIP 1.0 UF 10% X7R
Reference
Designator
Motorola
Part Number
Description
C5251 2113743L01 CAP CHIP 220 PF 10% X7R
C5252 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5253 2113743L01 CAP CHIP 220 PF 10% X7R
C5255 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5256 2113743L01 CAP CHIP 220 PF 10% X7R
C5257 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5258 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5259 2113743L41 CAP CHIP 10000 PF 10% X7R
C5280 2113743L01 CAP CHIP 220 PF 10% X7R
C5282 2113743L41 CAP CHIP 10000 PF 10% X7R
C5283 2113743N24 CAP CHIP 8.2 PF + -.5PF
COG
C5284 2113743L41 CAP CHIP 10000 PF 10% X7R
C5285 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5287 2113743L41 CAP CHIP 10000 PF 10% X7R
C5288 2113743N24 CAP CHIP 8.2 PF + -.5PF
COG
C5289 2113743L01 CAP CHIP 220 PF 10% X7R
C5290 2113743L01 CAP CHIP 220 PF 10% X7R
C5291 2113743L41 CAP CHIP 10000 PF 10% X7R
C5292 2113743L01 CAP CHIP 220 PF 10% X7R
C5294 2113743L41 CAP CHIP 10000 PF 10% X7R
C5295 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5296 2113743L01 CAP CHIP 220 PF 10% X7R
C5297 2113743N07 CAP CHIP 1.5 PF +-.25PF
COG
C5299 2113743L41 CAP CHIP 10000 PF 10% X7R
C5300 2113743L01 CAP CHIP 220 PF 10% X7R
C5301 2113743L41 CAP CHIP 10000 PF 10% X7R
C5302 2113743L41 CAP CHIP 10000 PF 10% X7R
C5303 2113743L41 CAP CHIP 10000 PF 10% X7R
C5304 2113743L01 CAP CHIP 220 PF 10% X7R
C5305 2113743L01 CAP CHIP 220 PF 10% X7R
C5306 2113743L01 CAP CHIP 220 PF 10% X7R
C5307 2113743L01 CAP CHIP 220 PF 10% X7R
C5308 2113743L01 CAP CHIP 220 PF 10% X7R
C5309 2113743L41 CAP CHIP 10000 PF 10% X7R
Reference
Designator
Motorola
Part Number
Description
C5310 2113743L01 CAP CHIP 220 PF 10% X7R
C5311 2113743L41 CAP CHIP 10000 PF 10% X7R
C5312 2113743L01 CAP CHIP 220 PF 10% X7R
C5314 2113743L41 CAP CHIP 10000 PF 10% X7R
C5315 2185802B01 CAP 10V 4.7UF
C5316 2113743L09 CAP CHIP 470 PF 10% X7R
C5317 2113743L01 CAP CHIP 220 PF 10% X7R
C5318 2185802B01 CAP 10V 4.7UF
C5319 2113743L41 CAP CHIP 10000 PF 10% X7R
C5320 2113743N28 CAP CHIP 12.0 PF 5% COG
C5321 2113743L01 CAP CHIP 220 PF 10% X7R
C5322 2113743L41 CAP CHIP 10000 PF 10% X7R
C5323 2113743L50 CAP CHIP 33000 PF 10%
C5324 2113743L01 CAP CHIP 220 PF 10% X7R
C5325 2113743L50 CAP CHIP 33000 PF 10%
C5326 2113743N26 CAP CHIP 10.0 PF 5% COG
C5327 2113743N50 CAP CHIP 100 PF 5% COG
C5328 2113743N32 CAP CHIP 18.0 PF 5% COG
C5329 2113743N50 CAP CHIP 100 PF 5% COG
C5331 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5332 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5334 2113743L01 CAP CHIP 220 PF 10% X7R
C5335 2113743L50 CAP CHIP 33000 PF 10%
C5336 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5337 2113743L50 CAP CHIP 33000 PF 10%
C5338 2113743L01 CAP CHIP 220 PF 10% X7R
C5339 2113743N22 CAP CHIP 6.8 PF + -.5PF
COG
C5340 2113743L01 CAP CHIP 220 PF 10% X7R
C5341 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5342 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5343 2113743N34 CAP CHIP 22.0 PF 5% COG
C5344 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5345 2113743L09 CAP CHIP 470 PF 10% X7R
C5346 2113743L50 CAP CHIP 33000 PF 10%
C5347 2113743N34 CAP CHIP 22.0 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
