7-166 Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board

May 25, 2005 6881096C74-B

C5348 2113743L01 CAP CHIP 220 PF 10% X7R

C5349 2113743N22 CAP CHIP 6.8 PF + -.5PF

COG

C5350 2113743L50 CAP CHIP 33000 PF 10%

C5351 2113743L50 CAP CHIP 33000 PF 10%

C5352 2113743L01 CAP CHIP 220 PF 10% X7R

C5353 2113743L01 CAP CHIP 220 PF 10% X7R

C5354 2113743N42 CAP CHIP 47.0 PF 5% COG

C5356 2113743L50 CAP CHIP 33000 PF 10%

C5357 2113743L01 CAP CHIP 220 PF 10% X7R

C5358 2113743N26 CAP CHIP 10.0 PF 5% COG

C5360 2113743L50 CAP CHIP 33000 PF 10%

C5361 2113743L01 CAP CHIP 220 PF 10% X7R

C5362 2113743L01 CAP CHIP 220 PF 10% X7R

C5363 2113743L01 CAP CHIP 220 PF 10% X7R

C5364 2113743L17 CAP CHIP 1000 PF 10% X7R

C5365 2113743L01 CAP CHIP 220 PF 10% X7R

C5366 2113743L17 CAP CHIP 1000 PF 10% X7R

C5367 2113743L01 CAP CHIP 220 PF 10% X7R

C5368 2113743L17 CAP CHIP 1000 PF 10% X7R

C5370 2113743N17 CAP CHIP 4.3 PF +-.25PF

COG

C5374 2113743N25 CAP CHIP 9.1 PF + -.5PF

COG

C5375 2113743N25 CAP CHIP 9.1 PF + -.5PF

COG

C5377 2113743N28 CAP CHIP 12.0 PF 5% COG

C5379 2113743N24 CAP CHIP 8.2 PF + -.5PF

COG

C5382 2113743L41 CAP CHIP 10000 PF 10% X7R

C5383 2113743L41 CAP CHIP 10000 PF 10% X7R

C5385 2113743L41 CAP CHIP 10000 PF 10% X7R

C5386 2113743N38 CAP CHIP 33.0 PF 5% COG

C5388 2113743L41 CAP CHIP 10000 PF 10% X7R

C5389 2113743N25 CAP CHIP 9.1 PF + -.5PF

COG

C5390 2113743N22 CAP CHIP 6.8 PF + -.5PF

COG

C5391 2113743N38 CAP CHIP 33.0 PF 5% COG

C5400 2113743L01 CAP CHIP 220 PF 10% X7R

C5401 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

Reference

Designator

Motorola

Part Number

Description

C5402 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C5403 2113743N29 CAP CHIP 13.0 PF 5% COG

C5404 2113743N30 CAP CHIP 15.0 PF 5% COG

C5405 2113743N12 CAP CHIP 2.7 PF +-.25PF

COG

C5406 2113743N31 CAP CHIP 16.0 PF 5% COG

C5407 2113743N30 CAP CHIP 15.0 PF 5% COG

C5408 2113743N13 CAP CHIP 3.0 PF +-.25PF

COG

C5409 2104801Z12 CAP CER NPO 1.8PF 16V

1005 SMD

C5410 2104801Z12 CAP CER NPO 1.8PF 16V

1005 SMD

C5412 2113743N12 CAP CHIP 2.7 PF +-.25PF

COG

C5413 2104801Z12 CAP CER NPO 1.8PF 16V

1005 SMD

C5414 2113743N24 CAP CHIP 8.2 PF + -.5PF

COG

C5415 2113743N12 CAP CHIP 2.7 PF +-.25PF

COG

C5418 2104801Z12 CAP CER NPO 1.8PF 16V

1005 SMD

C5419 2113743L01 CAP CHIP 220 PF 10% X7R

C5420 2113743L41 CAP CHIP 10000 PF 10% X7R

C5423 2113743L41 CAP CHIP 10000 PF 10% X7R

C5424 2113743L41 CAP CHIP 10000 PF 10% X7R

C5425 2113743L01 CAP CHIP 220 PF 10% X7R

C5426 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C5427 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C5428 2113743L01 CAP CHIP 220 PF 10% X7R

C5431 2113743L01 CAP CHIP 220 PF 10% X7R

C5433 2113743L41 CAP CHIP 10000 PF 10% X7R

C5501 2311049A78 CAP TANT CHIP 10.0 UF 10%

50V

C5502 2113743N12 CAP CHIP 2.7 PF +-.25PF

COG

C5503 2113743L50 CAP CHIP 33000 PF 10%

C5504 2113743L01 CAP CHIP 220 PF 10% X7R

C5505 2113743E20 CAP CHIP .10 UF 10%

C5506 2113743N26 CAP CHIP 10.0 PF 5% COG

Reference

Designator

Motorola

Part Number

Description

C5507 2113743N16 CAP CHIP 3.9 PF +-.25PF

COG

C5508 2113743L01 CAP CHIP 220 PF 10% X7R

C5509 2113743N50 CAP CHIP 100 PF 5% COG

C5510 2113743E20 CAP CHIP .10 UF 10%

C5512 2113743N44 CAP CHIP 56.0 PF 5% COG

C5513 2113743L48 CAP CHIP 22,000 PF 10%

C5515 2113743L48 CAP CHIP 22,000 PF 10%

C5516 2113743L01 CAP CHIP 220 PF 10% X7R

C5517 2113743E20 CAP CHIP .10 UF 10%

C5518 2113743N36 CAP CHIP 27.0 PF 5% COG

C5520 2113743N19 CAP CHIP 5.1 PF + -.5PF

COG

C5523 2113743N26 CAP CHIP 10.0 PF 5% COG

C5524 2113743N19 CAP CHIP 5.1 PF + -.5PF

COG

C5525 2113743L01 CAP CHIP 220 PF 10% X7R

C5526 2113741N69 CAP CHIP CL2 X7R 10%

100000

C5527 2113740A55 CAP,CHIP,100PF,,+5%,-

5%,50V-DC,0805

C5535 2111078B35 CAP CHIP RF 51 5 NPO 100V

C5538 2111078B35 CAP CHIP RF 51 5 NPO 100V

C5539 2113740A55 CAP,CHIP,100PF,,+5%,-

5%,50V-DC,0805

C5540 2113740A55 CAP,CHIP,100PF,,+5%,-

5%,50V-DC,0805

C5541 2113743E20 CAP CHIP .10 UF 10%

C5542 2111078B27 CAP CHIP RF 30 5 NPO 100V

C5543 2111078B27 CAP CHIP RF 30 5 NPO 100V

C5544 2113743E20 CAP CHIP .10 UF 10%

C5545 2111078B25 CAP CHIP RF 27 5 NPO 100V

C5546 2111078B25 CAP CHIP RF 27 5 NPO 100V

C5548 2111078B15 CAP CHIP RF 12 5 NPO 100V

C5549 2111078B42 CAP CHIP RF 100 5 NPO

100V

C5550 2113741N69 CAP CHIP CL2 X7R 10%

100000

C5551 2111078B13 CAP CHIP RF 10 .5 NPO 100V

C5552 2111078B05 CAP CHIP RF 4.7 .25 NPO

100V

C5553 2111078B42 CAP CHIP RF 100 5 NPO

100V

Reference

Designator

Motorola

Part Number

Description

C5554 2113743L41 CAP CHIP 10000 PF 10% X7R

C5555 2113743L01 CAP CHIP 220 PF 10% X7R

C5556 2113743L41 CAP CHIP 10000 PF 10% X7R

C5557 2113743L41 CAP CHIP 10000 PF 10% X7R

C5558 2113743L41 CAP CHIP 10000 PF 10% X7R

C5559 2111078B21 CAP CHIP RF 20 5 NPO 100V

C5560 2111078B21 CAP CHIP RF 20 5 NPO 100V

C5565 2113743L50 CAP CHIP 33000 PF 10%

C5566 2113743N21 CAP CHIP 6.2 PF + -.5PF

COG

C5570 2113741N69 CAP CHIP CL2 X7R 10%

100000

C5571 2311049A78 CAP TANT CHIP 10.0 UF 10%

50V

C5572 2311049C47 CAP TANT CHIP 22.0UF 10%

16V

C5573 2113741N69 CAP CHIP CL2 X7R 10%

100000

C5575 2113743L41 CAP CHIP 10000 PF 10% X7R

C5576 2113743L01 CAP CHIP 220 PF 10% X7R

C5578 2113743L01 CAP CHIP 220 PF 10% X7R

C5579 2113743L01 CAP CHIP 220 PF 10% X7R

C5580 2113743L01 CAP CHIP 220 PF 10% X7R

C5677 2113743L41 CAP CHIP 10000 PF 10% X7R

C5681 2113743L41 CAP CHIP 10000 PF 10% X7R

C5701 2113743L01 CAP CHIP 220 PF 10% X7R

C5702 2113743L01 CAP CHIP 220 PF 10% X7R

C5703 2113743L01 CAP CHIP 220 PF 10% X7R

C5704 2113743L01 CAP CHIP 220 PF 10% X7R

C5705 2111078A06 CAP CHIP RF 1.5 .25 NPO

100V

C5706 2111078B06 CAP CHIP RF 5.1 .25 NPO

100V

C5707 2111078A01 CAP CHIP RF 1 .25 NPO 100V

C5708 2111078B42 CAP CHIP RF 100 5 NPO

100V

C5709 2111078B34 CAP CHIP RF 47 5 NPO 100V

C5710 2113743N46 CAP CHIP 68.0 PF 5% COG

C5711 2111078B01 CAP CHIP RF 3.3 .25 NPO

100V

C5712 2111078B03 CAP CHIP RF 3.9 .25 NPO

100V

C5713 2111078B14 CAP CHIP RF 11 5 NPO 100V

Reference

Designator

Motorola

Part Number

Description
