Motorola ASTRO Digital XTL 5000 Detailed Service Manual

Interconnect Boards Schematics, Component Location Diagrams, and Parts Lists: Remote Interconnect Boards (Mid Power Only) 8-7
6881096C74-B May 25, 2005
HLN6885A/B Remote Interconnect Board (W3 Hand-Held
Control Head) Parts List
R673 NOTPLACED
R674 NOTPLACED
R675 NOTPLACED
R676 NOTPLACED
R678 NOTPLACED
U600 NOTPLACED
U601 NOTPLACED
U602 NOTPLACED
U603 NOTPLACED
VR624 NOTPLACED
VR625 NOTPLACED
VR627 NOTPLACED
VR671 NOTPLACED
VR672 NOTPLACED
Reference
Designator
Motorola
Part Number
Description
PCB 8485919E01 PCB INTERCONNECT
HLN6885B
- 1010041C22 SOLDER PASTE
- 1105033S02 RIBBON LABEL LT. PACK
LABEL
- 1105033S13 RIBBON LBL
- 5405569Y02 LBL BARCODE APC
- 5405569Y03 LABEL BARCODE
HD001 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD002 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD003 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD004 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
JU512 0611077A01 RES CHIP JUMPER
JU513 0611077A01 RES CHIP JUMPER
JU600 0611077A01 RES CHIP JUMPER
JU602 0611077A01 RES CHIP JUMPER
JU604 0611077A01 RES CHIP JUMPER
JU606 0611077A01 RES CHIP JUMPER
Reference
Designator
Motorola
Part Number
Description
JU607 0611077A01 RES CHIP JUMPER
JU608 0611077A01 RES CHIP JUMPER
JU609 0611077A01 RES CHIP JUMPER
JU613 0611077A01 RES CHIP JUMPER
JU616 0611077A01 RES CHIP JUMPER
JU618 0611077A01 RES CHIP JUMPER
JU619 0611077A01 RES CHIP JUMPER
JU620 0611077A01 RES CHIP JUMPER
JU621 0611077A01 RES CHIP JUMPER
JU622 0611077A01 RES CHIP JUMPER
JU623 0611077A01 RES CHIP JUMPER
JU626 0611077A01 RES CHIP JUMPER
JU632 0611077A01 RES CHIP JUMPER
JU633 0611077A01 RES CHIP JUMPER
JU634 0611077A01 RES CHIP JUMPER
JU635 0611077A01 RES CHIP JUMPER
JU637 0611077A01 RES CHIP JUMPER
JU638 0611077A01 RES CHIP JUMPER
JU640 0611077A01 RES CHIP JUMPER
JU641 0611077A01 RES CHIP JUMPER
JU642 0611077A01 RES CHIP JUMPER
JU650 0611077A01 RES CHIP JUMPER
JU652 0611077A01 RES CHIP JUMPER
JU654 0611077A01 RES CHIP JUMPER
JU656 0611077A01 RES CHIP JUMPER
JU672 0611077A01 RES CHIP JUMPER
JU673 0611077A01 RES CHIP JUMPER
JU676 0611077A01 RES CHIP JUMPER
JU678 0611077A01 RES CHIP JUMPER
JU679 0611077A01 RES CHIP JUMPER
R608 0611077A01 RES CHIP JUMPER
R670 0611077A26 RES CHIP 10 5 1/8W
R620 0611077A54 RES CHIP 150 5 1/8W
R621 0611077A74 RES CHIP 1000 5 1/8
R623 0611077A74 RES CHIP 1000 5 1/8
R676 0611077A74 RES CHIP 1000 5 1/8
R678 0611077A74 RES CHIP 1000 5 1/8
R618 0611077A96 RES CHIP 8200 5 1/8
R671 0611077A98 RES CHIP 10K 5 1/8W
R673 0611077A98 RES CHIP 10K 5 1/8W
R609 0611077B15 RES CHIP 47K 5 1/8W
Reference
Designator
Motorola
Part Number
Description
R610 0611077B15 RES CHIP 47K 5 1/8W
R619 0611077B15 RES CHIP 47K 5 1/8W
R622 0611077B15 RES CHIP 47K 5 1/8W
R672 0611077B15 RES CHIP 47K 5 1/8W
R675 0611077B15 RES CHIP 47K 5 1/8W
R612 0611077B23 RES CHIP 100K 5 1/8W
R615 0611077B23 RES CHIP 100K 5 1/8W
R616 0611077B23 RES CHIP 100K 5 1/8W
R617 0611077B23 RES CHIP 100K 5 1/8W
R624 0611077B23 RES CHIP 100K 5 1/8W
R625 0611077B23 RES CHIP 100K 5 1/8W
R674 0611077B23 RES CHIP 100K 5 1/8W
J5 0980159P02 CONNECTOR 25-PIN
J6 0980159P02 CONNECTOR 25-PIN
C789 2109822S06 CAP CHIP CER 10UF 16V
C791 2109822S06 CAP CHIP CER 10UF 16V
C792 2109822S09 CAP CERAMIC CHIP 1UF
20 50V
C732 2113740B65 CAP CHIP REEL CL1 +/-30
470
C750 2113740B65 CAP CHIP REEL CL1 +/-30
470
C751 2113740B65 CAP CHIP REEL CL1 +/-30
470
C752 2113740B65 CAP CHIP REEL CL1 +/-30
470
C753 2113740B65 CAP CHIP REEL CL1 +/-30
470
C754 2113740B65 CAP CHIP REEL CL1 +/-30
470
C755 2113740B65 CAP CHIP REEL CL1 +/-30
470
C756 2113740B65 CAP CHIP REEL CL1 +/-30
470
C757 2113740B65 CAP CHIP REEL CL1 +/-30
470
C758 2113740B65 CAP CHIP REEL CL1 +/-30
470
C759 2113740B65 CAP CHIP REEL CL1 +/-30
470
C760 2113740B65 CAP CHIP REEL CL1 +/-30
470
C761 2113740B65 CAP CHIP REEL CL1 +/-30
470
Reference
Designator
Motorola
Part Number
Description
C762 2113740B65 CAP CHIP REEL CL1 +/-30
470
C763 2113740B65 CAP CHIP REEL CL1 +/-30
470
C764 2113740B65 CAP CHIP REEL CL1 +/-30
470
C765 2113740B65 CAP CHIP REEL CL1 +/-30
470
C766 2113740B65 CAP CHIP REEL CL1 +/-30
470
C767 2113740B65 CAP CHIP REEL CL1 +/-30
470
C768 2113740B65 CAP CHIP REEL CL1 +/-30
470
C769 2113740B65 CAP CHIP REEL CL1 +/-30
470
C770 2113740B65 CAP CHIP REEL CL1 +/-30
470
C771 2113740B65 CAP CHIP REEL CL1 +/-30
470
C772 2113740B65 CAP CHIP REEL CL1 +/-30
470
C773 2113740B65 CAP CHIP REEL CL1 +/-30
470
C774 2113740B65 CAP CHIP REEL CL1 +/-30
470
C779 2113740B65 CAP CHIP REEL CL1 +/-30
470
C780 2113740B65 CAP CHIP REEL CL1 +/-30
470
C781 2113740B65 CAP CHIP REEL CL1 +/-30
470
C783 2113740B65 CAP CHIP REEL CL1 +/-30
470
C790 2113740B65 CAP CHIP REEL CL1 +/-30
470
C785 2113741N69 CAP CHIP CL2 X7R 10%
100000
C786 2113741N69 CAP CHIP CL2 X7R 10%
100000
C794 2113741N69 CAP CHIP CL2 X7R 10%
100000
C795 2113741N69 CAP CHIP CL2 X7R 10%
100000
C796 2113741N69 CAP CHIP CL2 X7R 10%
100000
Reference
Designator
Motorola
Part Number
Description
