Motorola ASTRO Digital XTL 5000

8-8 Interconnect Boards Schematics, Component Location Diagrams, and Parts Lists: Remote Interconnect Boards (Mid Power Only)
May 25, 2005 6881096C74-B
C797 2113741N69 CAP CHIP CL2 X7R 10%
100000
C798 2113741N69 CAP CHIP CL2 X7R 10%
100000
P506 2880068M01 HEADER MIC
P502 2885361E01 CONN 38 PIN MALE (RM
CH)
CR600 4805218N57 DIODE DUAL
CR601 4805218N57 DIODE DUAL
D602 4805218N57 DIODE DUAL
D603 4805218N57 DIODE DUAL
D605 4805218N57 DIODE DUAL
VR675 4805656W03 DIODE DUAL 5.6V ZENER
VR614 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR615 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR616 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR617 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR671 4805656W10 DIODE DUAL 15 VOLT
ZENER
Q603 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q604 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q606 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q602 4813821A09 TSTR P-CH 60V 12A
_2955_
VR600 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR601 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR602 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR603 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR604 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR605 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR606 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
Reference
Designator
Motorola
Part Number
Description
VR607 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR608 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR609 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR610 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR611 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR612 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR613 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR618 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR619 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR620 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR621 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR622 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR623 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR624 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR625 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR627 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR672 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR673 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR674 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
U601 5113806A05 IC FLIP-FLOP,DUAL D
U603 5113816A19 IC ADJ LO DROPOUT POS
REG .8A
U602 5113818A06 IC LOW PWR SING SPLY
MC33172DR
C776 NOTPLACED 64AM DUMMY PART
NUMBER
C777 NOTPLACED
C778 NOTPLACED
Reference
Designator
Motorola
Part Number
Description
C793 NOTPLACED
D600 NOTPLACED
F600 NOTPLACED
GS1 NOTPLACED
GS2 NOTPLACED
JU10 NOTPLACED
JU11 NOTPLACED
JU12 NOTPLACED
JU601 NOTPLACED
JU603 NOTPLACED
JU605 NOTPLACED
JU610 NOTPLACED
JU611 NOTPLACED
JU612 NOTPLACED
JU614 NOTPLACED
JU615 NOTPLACED
JU617 NOTPLACED
JU624 NOTPLACED
JU625 NOTPLACED
JU627 NOTPLACED
JU628 NOTPLACED
JU629 NOTPLACED
JU630 NOTPLACED
JU631 NOTPLACED
JU636 NOTPLACED
JU643 NOTPLACED
JU644 NOTPLACED
JU645 NOTPLACED
JU651 NOTPLACED
JU653 NOTPLACED
JU655 NOTPLACED
JU657 NOTPLACED
JU658 NOTPLACED
JU671 NOTPLACED
JU674 NOTPLACED
JU675 NOTPLACED
JU677 NOTPLACED
JU700 NOTPLACED
JU800 NOTPLACED
Q605 NOTPLACED
R600 NOTPLACED
Reference
Designator
Motorola
Part Number
Description
R601 NOTPLACED
R602 NOTPLACED
R603 NOTPLACED
R604 NOTPLACED
R605 NOTPLACED
R606 NOTPLACED
R607 NOTPLACED
R613 NOTPLACED
R614 NOTPLACED
U600 NOTPLACED
Reference
Designator
Motorola
Part Number
Description
