Specifications
xvi
Specifications for VHF Radios
All specifications are per Telecommunications Industries Association TIA-603, unless otherwise noted.
GENERAL RECEIVER TRANSMITTER
FCC ID:
136–174 MHz: AZ489FT3807
Temperature Range:
Operating: -30°C to +60°C
Storage: -40°C to +85°C
Power Supply: Nickel-Cadmium Battery (NiCd)
or Nickel-Metal-Hydride Battery (NiMH)
Battery Voltage:
Nominal: 7.5 Volts
Range: 6 to 9 Volts
Transmit Current Drain (typical): 1900mA
Receive Current Drain (Rated Audio): 220mA
Standby Current Drain: 70mA
Dimensions: Height x Width x Depth
Radio Less Battery: 6.0" x 2.3" x 1.5"
With NiCd Ultra-High Cap.: 6.0" x 2.3" x 2.0"
With NiMH Ultra-High Cap.: 6.0" x 2.3" x 2.0"
Weight
Radio Less Battery: 11.0 oz.
With NiCd Ultra-High Capacity: 20.0 oz.
With NiMH Ultra-High Capacity: 20.5 oz.
Frequency Range: 136–174 MHz
Quieting Sensitivity (typical) (20dBQ): 0.23µV
Usable Sensitivity (typical):
(12dB SINAD): 0.25µV
Intermodulation (typical): -78dB
Selectivity (typical):
(25kHz Channel): -70dB
(12.5kHz Channel): -63dB
Spurious Rejection (typical): -80dB
Frequency Stability:
(–30+60°C; 25°C reference): 2.5ppm
Rated Audio: 500mW
FM Hum and Noise (typical):
(25kHz channel): -52dB
(12.5kHz channel): -40dB
Distortion (at Rated Audio; typical): 1%
Channel Spacing: 12.5/25 kHz
Frequency Range: 136–174 MHz
RF Power:
136–174 MHz: 5 Watts
Frequency Stability (typical):
(–30 to +60°C; 25°C ref.): 2.5ppm
Emission (typical conducted): -73 dBc<1GHz
FM Hum and Noise (typical):
(25 kHz channel): -46dB
(12.5 kHz channel): -42dB
Distortion (typical): 1%
Modulation Limiting: 25 kHz chnls ±5.0kHz
12.5 kHz chnls ±2.5kHz
Emissions Designators: 16K0F3E,11K0F3E,
8K10F1D, and 8K10F1E
(Encryption): 20K0F1E
