Recommended Test Equipment and Service Aids
12
any equivalent item capable of the same performance may be substituted for the
item listed.
NOTE: The Radio Interface Box (RIB), Smart Radio
Interface Box (SRIB), and any cable that connects
with those boxes are incompatible with the XTS
2500 radio and should NOT be used.
Field
Programming
Equipment
This family of radios can be aligned and programmed in the field. This requires
specific equipment and special instructions. Refer to the applicable “CPS On-line
Help” for complete field programming information.
Table 4. Service Aids
Motorola Part
Number
Description Application
– Standard Hex Shank Screw
Bit (7/64)
To remove/screw hex nut (0286165A03) for non-Immersible
model.
6685666D01 Chassis Opener Tool Used to remove radio knobs and to separate chassis from
Front Cover.
NLN9839_ Vacuum Pump Kit Immersible radios only. Vacuum pump with gauge and
vacuum hose. Requires NTN9279 Adapter Kit.
NTN4265_ Pressure Pump Kit Immersible radios only. Pressure pump with gauge and
pressure hose. Requires NTN9279 Adapter Kit.
NTN9279_ Vacuum Adapter with Gasket
Kit
Immersible radios only. Connects the vacuum/pressure
hose to the radio’s casting.
RKN-4106_ RS232/Radio/Test Set Cable Connects radio to RLN4460 Test Box and to RS232
computer connector (DB9).
0180305G54 Battery Eliminator Interconnects radio to power supply.
RLN-4460_ Portable Test Set Enables connection to the universal connector.
Allows switching for radio testing.
RVN-4181_ Customer Programming
Software
Customer Programming Software (CPS)/Tuner on one
CD-ROM.
58-80348B33 SMA to BNC Adaptor Adapts radio’s antenna port to BNC cabling of test
equipment.
RKN4105_ USB/Radio/Test Set Cable Connects radio to RLN4460 test box and to USB computer
connector.
8180384M37 Test Fixture Provides for troubleshooting the radio board when the back
casting is removed.
