Radio Alignment
Procedures 6
Introduction to
This Section
This section describes both receiver and transmitter radio alignment procedures.
General A personal computer (PC) and tuner software are required to align the radio. Refer
to the applicable manual for installation and setup procedures for the software. To
perform the alignment procedures, the radio must be connected to the PC and to
a universal test set as shown in Figure 4. Radio Alignment Test Setup on page 13.
These procedures should only be attempted by qualified service
personnel. Failure to perform alignment procedures properly may
result in seriously degraded radio or system performance.
C a u t i o n
