2-7
POWER
SUPPLY
BAT
AUX
DC
ON
OFF
PWR
PWR
IN
Customer Cable
FKN4465
Power Supply
Module - Less
(FPN5957)
Solar Panel Battery
Portable Radio
Note: Place Line filter here.
Refer to Chapter 7
FKN8024
FKN4469
Figure 2-8 External DC Power Source Connections – Using Portable Radio on Wall
Mount or NEMA4X Housing Enclosure
